LREC6822XF-2SFP+ LR-Link PCIe x8 3.0 10 Gigabit Dual-port Fiber Ethernet Adapter(Mellanox ConnectX-3)

Features

Controller

Mellanox ConnectX-3

Interface

SFP LC Port

Bracket

Low Profile Bracekt and Full-height Bracket

Power dissipation

6W

Operating system support

Windows Server 2016 R2

Windows Server 2012 R2

Windows Server 2012

Windows Server 2008 R2

Windows10

Windows 8.1

Windows 8

Windows 7 X64

Linux Stable Kernel version 2.6,3.x,4.x etc

Ubuntu 12.04 etc

Vmware ESXi4.x 5.x 6.x

Citrix XenServer 6.1

Connector

2 xSFP+

PCI Express Card Type

PCI Express v3.0 (8.0GT s) x8  x4,x16

Data Transfer Rate

10 GbE, 2000Mbit s in full duplex mode per port

PCI Express Voltage

 +12V±8%，+3.3V±8%

Technical Specification

Ethernet Power Management

Yes

Speed

10GbE

IEEE Standard Network topology

IEEE 802.11ae 10GBase-SR  10GBase-LR  10GBase-ER  10GBase-ZR
IEEE 802.3aq  10GBase-LRM

IEEE 802.3ad Link Aggregation and Failover

IEEE 802.3az Energy Efficient Ethernet

IEEE 802.1Q.1p VLAN tags and priority

IEEE 802.1Qau  Congestion Notification

IEEE P802.1Qbb D1.0 Priority-based Flow Control

IEEE 1588 Precision Clock Synchronization

Jumbo frame support (1024B)

PXE

Yes（iPXE）

Iscsi

Yes

Power management

Yes

SR-IOV

Yes

IPv4,IPv6

Support

RSS

Support

Jumbo frame packet

Yes

DPDK

Support

NFV

Yes

VLAN

SupportVXLAN, NVGRE

Operating Environment

Operating Temperature

0℃to 50℃ (32℉to 122℉)

Storage Temperature

-40℃to 85℃ (-40℉ to 185℉)

Operating Relative Humidity

35% to 90%, non condensing

LEDs

Link: Turns on link (orange)

Act:10Gb s on activity (green)

Driver

Drivers Download

Windows

http: www.mellanox.com page products_dyn?product_family=32&mtag=w indows_driver

System: http: www.mellanox.com page software_overview_eth

Windows

Mellanox Connect X-3 Ethernet Adapter

Linux

Mellanox Technologies MT27520 Family

Firmware Update

http: www.mellanox.com supportdownloader

Testing Report

Server Client

CPU：INTEL Xeon E5-2658 V3 2.0GHz

Motherboard：Giada JHS827-AST1400

RAM：SKhynix 8 GB DDR4

OS：Windows Server 2016 R2

TCP bandwidth Throughput testing

Test the topology：S-C

Server：IxChariot6.7

Client：IxChariot6.7

Latency time

Data packet length（byte）

TCP

UDP

32

9.8us

8.7us

PCB Size（mm）

159.50mm X 68.76mm X 1.6mm
