Port Hızı |
1Gb |
Port Tipi |
SFP |
Port Sayısı |
1 Port |
ChipSet Marka |
Intel |
ChipSet |
INTEL 82576 |
Genel Özellikler
- Single-port 1000Mbps adapter
- PCI Express (PCIe) 2.0, 2.5 GT/s, x4 lane
- SFP LC Connectivity
- Network Virtualization
- ISCSI remote boot support
- Load balancing on multiple CPUs
- Support for most network operating systems(NOS)
- Simple Network Management Protocol(SNMP) and Remote Network Monitoring(RMON) Statistic Counters
- Low profile and full -height Bracket
Controller
Intel 82576
Transmission rate per port
1 GbE
Network Standard Physical Layer Interfaces
1000BASE-SX: 275 m at 62.5 µm; 550 m at 50 µm
1000BASE-LX: 10Km at 9µm
Jumbo Frame Support
Up to 9.5 KB
Operating Temperature
0 °C to 55 °C (32 °F to 131 °F)
Network Virtualization
VLAN, VEPA
LED Indicators OPERATION
Link LED:Green; ACT LED:Yellow
Operating System Support
Windows Server 2016 R2/2012 R2/2012/2008 R2/2008/2003 R2/2003
WindowsXP/Vista/7/8/8.1/10
Linux Kernel version 2.6.x/3.x/4.x orlater FreeBSD 7.x UnixWare / Open Unix 8
VMware ESX/ESXi 5.x/6.x orlater Sun Solaris 9/10/11
