Controller
|
Intel I350
|
Transmission Rate Per Port
|
10/100/1000 Mbps
|
Network Standard Physical Layer Interfaces
|
1000BASE-T:Cat 5eor higherup to 100m
|
100BASE-Tx:Cat5e/6or higherup to 100m
|
Jumbo Frame Support
|
Up to 9.5 KB
|
Operating Temperature
|
0 °C to 55°C (32 °F to 131°F)
|
Boot Option and Virtualization
|
PXE support, Intel® VT-c
|
LED Indicators
|
1000Mbps/s:Yellow Link and Green Ack
|
100Mbps/s:Green Link and Green Ack
|
Operating System Support
|
Windows Server2003/ 2008 /2008 R2 / 2012 /2012 R2 /2016 R2
|
WindowsXP / Vista /7 / 8 / 8.1 / 10
|
Linux Stable Kernel version 2.4.x / 2.6.x/ 3.x/ 4.xor later
|
Linux SLES 9 / 10 / 11or later
|
VMwareESX/ESXi4.x/5.x/6.xor later
|
